Specification | |
Model No | 605080 |
Nominal capacity | 3000mAh |
Nominal voltage | 3.7V |
Charging cut-off voltage | 4.2V |
Discharge cut-off voltage | 3.0V |
Dimension | 6.0mm*50mm*80mm |
Weight | 58g |
Cycle life | 500 times |
Suitable charge current | 0.5c |
Maximum continuous discharge current | 1.0c |
Temperature range | Charge 0 - 45 ℃ |
Discharge -20 - 60 ℃ | |
Storage -20 - 35 ℃ | |
Storage Voltage | 3.7--3.85V |
Key Features 1.High energy density lithium polymer battery. 2.Long cycle life,more than 500 cycles. 3.Environmental Friendly Chemistry 4.Minimal self-discharge | |
Application: GPS terminal.Barcode Reader,POS machine.protable electronic cash register,Bluetooth headset. sensor,smoke detetors,digital cameras,solar lights,vehicle tracking,Animal food device and so on. |
The below model list is only for reference. | ||||||||
No. | Model | Capacity | Nominal Voltage | Dimensions (mm) | Weight | |||
Typical | Nominal | Thickness | Width | Height | Approx. (g) | |||
(mAh) | (mAh) | (V) | (±0.2) | (±0.8) | (±0.8) | |||
1 | 309095 | 3000 | 2900 | 3.7 | 3 | 90 | 95 | 55 |
2 | 4049100 | 3000 | 2900 | 3.7 | 4.0 | 49 | 100 | 55 |
3 | 425685 | 2700 | 2600 | 3.7 | 4.0 | 56 | 85 | 53 |
4 | 505095 | 3000 | 2900 | 3.7 | 5.0 | 50 | 95 | 55 |
5 | 505080 | 2300 | 2200 | 3.7 | 5.0 | 50 | 80 | 44 |
6 | 505085 | 2500 | 2400 | 3.7 | 5.0 | 50 | 85 | 46 |
7 | 555068 | 2050 | 2000 | 3.7 | 5.5 | 50 | 68 | 38 |
8 | 606065 | 2500 | 2400 | 3.7 | 6.0 | 60 | 65 | 48 |
9 | 605068 | 2500 | 2400 | 3.7 | 6.0 | 50 | 68 | 52 |
10 | 6060100 | 5000 | 4900 | 3.7 | 6.0 | 60 | 100 | 100 |
11 | 655565 | 2800 | 2700 | 3.7 | 6.5 | 55 | 65 | 53 |
12 | 705060 | 2700 | 2600 | 3.7 | 7.0 | 50 | 60 | 53 |
13 | 704090 | 3350 | 3250 | 3.7 | 7.0 | 40 | 90 | 56 |
14 | 7045120 | 5000 | 4900 | 3.7 | 7.0 | 45 | 120 | 100 |
15 | 754068 | 2500 | 2400 | 3.7 | 7.5 | 40 | 68 | 52 |
16 | 804668 | 3200 | 3100 | 3.7 | 8.0 | 46 | 68 | 56 |
17 | 805050 | 5000 | 4900 | 3.7 | 8.0 | 50 | 50 | 100 |
18 | 803860 | 2050 | 2000 | 3.7 | 8.0 | 38 | 60 | 38 |
19 | 855085 | 4100 | 4000 | 3.7 | 8.5 | 50 | 85 | 90 |
20 | 906070 | 5000 | 4900 | 3.7 | 9.0 | 60 | 70 | 100 |
21 | 904272 | 3300 | 3200 | 3.7 | 9.0 | 42 | 72 | 56 |
22 | 953090 | 2900 | 2800 | 3.7 | 9.5 | 30 | 90 | 54 |
23 | 105590 | 6000 | 5900 | 3.7 | 10.0 | 55 | 90 | 110 |
24 | 103759 | 2600 | 2500 | 3.7 | 10.0 | 37 | 59 | 48 |
25 | 104050 | 2500 | 2400 | 3.7 | 10.0 | 40 | 50 | 48 |
26 | 105050 | 3000 | 2900 | 3.7 | 10.0 | 50 | 50 | 54 |
27 | 113555 | 2500 | 2400 | 3.7 | 11.0 | 35 | 55 | 48 |
28 | 113868 | 3600 | 3500 | 3.7 | 11.0 | 38 | 68 | 57 |
29 | 125060 | 4500 | 4400 | 3.7 | 12.0 | 50 | 60 | 95 |
30 | 126090 | 8000 | 7900 | 3.7 | 12.0 | 60 | 90 | 189 |
